NRD1 Antikörper (Middle Region)

Produktnummer ABIN2787813

Produktdetails anti-NRD1 Antikörper

Target: NRD1 (Nardilysin (N-Arginine Dibasic Convertase) (NRD1))

Bindungsspezifität: Middle Region

Reaktivität: Human, Pferd, Schwein, Rind (Kuh)

Wirt: Kaninchen

Klonalität: Polyklonal

Konjugat: Dieser NRD1 Antikörper ist unkonjugiert

Applikation: Western Blotting (WB)

Sequenz: GSKMLSVHVV GYGKYELEED GTPSSEDSNS SCEVMQLTYL PTSPLLADCI

Homologie: Cow: 93%, Horse: 86%, Human: 100%, Pig: 93%

Produktmerkmale: This is a rabbit polyclonal antibody against NRD1. It was validated on Western Blot using a cell lysate as a positive control.

Aufreinigung: Affinity Purified

Immunogen: The immunogen is a synthetic peptide directed towards the middle region of human NRD1

Anwendungsinformationen

Applikationshinweise: Optimal working dilutions should be determined experimentally by the investigator.

Kommentare:

Antigen size: 1151 AA

Beschränkungen: Nur für Forschungszwecke einsetzbar

Independent Validation (IHC)

Validierung #103724 (Immunohistochemistry)

by: AG Deeg, Lehrstuhl für Physiologie, Veterinärwissenschaftliches Department, Tierärztliche Fakultät, Ludwig-Maximilians-Universität München

No.: #103724

Datum: 19.07.2019

Antigen: NRD1

Chargennummer: QC27244-100203

Validierte Anwendung: Immunohistochemistry

Positivkontrolle:

retina from horses suffering from equine recurrent uveitis (ERU)

Negativkontrolle:

retina from non-ERU infected horses

isolated equine retinal Müller glial cells (eqMCs)

Bewertung:

Passed. The NRD1 antibody ABIN2787813 specifically labels the targeted antigen in retinae from horses suffering from ERU and in isolated equine retinal Müller glial cells.

Validierungsbilder

IHC staining of NRD1 using ABIN2787813 (red, middle) on retina from horses suffering from equine recurrent uveitis (A) and non-ERU infected horses (B). Counterstain with DAPI (blue) and an anti-Vimentin antibody (green).

IHC staining of NRD1 using ABIN2787813 (red, middle) on isolated equine retinal Müller glial cells. Counterstain with DAPI (blue) and an anti-Vimentin antibody (green).

Protokoll

Primärantikörper: ABIN5074774

Sekundärantikörper: goat anti-rabbit IgG (H+L) AF568-conjugated antibody (Invitrogen, A11036, lot 1832035)

Full Protocol:

• IHC on fixed equine retina:
• • Dissect tissue and fix in 4% buffered formalin for 12h at 4°C.
  • Dehydrate and paraffinize the tissue through a graded alcohole, xylene and paraffine series.
  • Embed the tissue in Richard Allen Scientific Paraffine Type 9 (Thermofisher, 8337).
  • Cut fixed tissue with a microtome into 8µm-thick sections.
  • Deparaffinization and rehydration through graded xylene and graded alcohol series:
  • Boil the sections in a 99°C hot waterbath in 0.1M Na2-EDTA buffer pH8.0 for 15min.
  • Boil the sections in a 99°C hot waterbath in citrate buffer pH6 (Dako, 2031) for 15min.
  • Rinse sections with PBS pH7.4.
• IHC on isolated eqMCs:
• • Prepare eqMCs from the eyes of a 19 year old mare.
  • Cultivate cells in DMEM (PAN-Biotech, P04-04510, lot 2650219) supplemented with 10% v/V FBS (Biochrom, S0615, lot 0879F) and 1% Penicillin/Streptomycin (PAN-Biotech, P06-07100, lot 7180417) for 18d at 37°C at 5% CO₂.
  • Seed 1x10⁵ cells (first passage) in 1ml medium on adhesion microscope slides (Langenbrinck 03-0060, lot 021218).
  • Incubate cells for 2d at 37°C at 5% CO₂.
  • Remove medium and wash cells with PBS pH7.4.
  • Fix cells for 10min with ice-cold acetone.
  • Rehydrate cells with TBST (0.01M Tris, 0.15M NaCl, 0.1% v/v Tween 20) pH7.3.
• Block samples in 5% goat serum in TBST pH7.3 containing 1% w/v BSA (BSA-TBST).
• Incubate samples with primary rabbit anti-NRD1 antibody (antibodies-online, ABIN2787813, lot QC27244-100203) diluted 1:100 in BSA-TBST ON at 4°C.
• Wash samples with BSA-TBST.
• Incubate samples with secondary goat anti-rabbit IgG (H+L) AF568-conjugated antibody (Invitrogen, A11036, lot 1832035) diluted 1:500 in BSA-TBST for 30min at RT.
• Wash samples with BSA-TBST.
• Incubate samples with primary mouse anti-Vimentin antibody (Sigma-Aldrich, V6630) diluted 1:400 in BSA-TBST ON at 4°C.
• Wash samples with BSA-TBST.
• Incubate samples with secondary goat anti-mouse IgG (H+L) AF488-conjugated antibody (Invitrogen, A11029, lot 1874804) diluted 1:500 in BSA-TBST containing 0.1% DAPI for 30min at RT.
• Wash samples with BSA-TBST.
• Mount samples in Fluoromount W mounting medium (SERVA, 21634, lot 181008).
• Acquire images with Leica DMi8 fluorescence microscope equipped with Filter Cubes for DAPI, FITC, TXR and Y5 at 200x (prepared retina) and 400x (eqMCs). Parameters for image acquisition (exposure: FITC 220ms, TXR 253ms, DAPI 195ms) were maintained unchanged for all images.

Anmerkungen:

ABIN2787813 was also tested in western blot on retinal Müller glial cell lysate from healthy horses or horses suffering from ERU and in equine and porcine total retinal lysates. However, the antibody did not detect a protein of the expected MW of 132kDa in any of these samples whereas numerous extraneous protein bands were detected.

Handhabung

Format: Liquid

Konzentration: Lot specific

Buffer: Liquid. Purified antibody supplied in 1x PBS buffer with 0.09 % (w/v) sodium azide and 2 % sucrose.

Konservierungsmittel: Sodium azide

Vorsichtsmaßnahmen: This product contains Sodium azide: a POISONOUS AND HAZARDOUS SUBSTANCE which should be handled by trained staff only.

Handhabung: Avoid repeated freeze-thaw cycles.

Lagerung: -20 °C

Informationen zur Lagerung: For short term use, store at 2-8°C up to 1 week. For long term storage, store at -20°C in small aliquots to prevent freeze-thaw cycles.

Details zu NRD1

Target: NRD1 (Nardilysin (N-Arginine Dibasic Convertase) (NRD1))

Andere Bezeichnung: NRD1 (NRD1 Produkte)

Synonyme: hNRD1 antikoerper, hNRD2 antikoerper, NRDC antikoerper, 2600011I06Rik antikoerper, AI875733 antikoerper, NRD-C antikoerper, NRD1 antikoerper, si:dkey-171o17.4 antikoerper, DKFZp459N143 antikoerper, nardilysin convertase antikoerper, nardilysin, N-arginine dibasic convertase, NRD convertase 1 antikoerper, nardilysin antikoerper, nardilysin b (N-arginine dibasic convertase) antikoerper, NRDC antikoerper, Nrdc antikoerper, Nrd1 antikoerper, LOC552055 antikoerper, nrd1b antikoerper, CpipJ_CPIJ002524 antikoerper, Tsp_03755 antikoerper

Hintergrund: NRD1 cleaves peptide substrates on the N-terminus of arginine residues in dibasic pairs.
Alias Symbols: hNRD1, hNRD2
Protein Interaction Partner: FBXW11, UBC, rev, SETSIP, PUS1, P3H1, ELAC2, XPO5, NSUN2, PDIA6, YARS, DNAJC7, TSN, PPP3CA, PPP2R2A, PPP2CA, PFDN5, PFDN1, PPP1R12A, MSH2, PNKP, HSPB1, MOB2, MOB1A, STK3, NRD1, HIST2H3C, UACA, COBLL1, NCOR2, NCOR1, HDAC3, IQGAP1, MAD1L1, TBL1X, UIMC1, BTR
Protein Size: 1151

Molekulargewicht: 132 kDa

Gen-ID: 4898

NCBI Accession: NM_001101662, NP_001095132

UniProt: O43847

Pathways: Skeletal Muscle Fiber Development
